MAGNA1 25-60 180 1x230V PN10

Description MAGNA1 25-60MAGNA1 circulator pump with easy selection of pump setting The pump is of the canned-rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid. In order to avoid problems in connection with disposal, great importance has been attached to using as few different materials as possible. A pump with no maintenance requirements and extremely low life cycle cost.Heating systemsMain pumpmixing loopsheating surfacesair-conditioning surfaces. The MAGNA1 circulator pumps are designed for circulating liquids in heating systems with variable flows where it is desirable to optimise the setting of the pump duty point, thus reducing energy costs. The pumps are also suitable for domestic hot-water systems. To ensure correct operation, it is important that the sizing range of the system falls within the duty range of the pump. BenefitsSafe selection.Simple installation.Low energy consumption. All MAGNA1 pumps comply with the EuP requirements.Nine light fields for indication of pump setting. Three proportional-pressure curves, three constant-pressure curves and three fixed-speed curves are available.Low noise level.No mainteance and long life.  Liquid:Pumped liquid:WaterLiquid temperature range:-10 .. 110 °CLiquid temperature during operation:60 °CDensity:983.2 kg/m³      Approvals on nameplate:CE,VDE,EAC,CN ROHSMaterials:Pump housing:Cast ironEN-GJL-200ASTM A48-200BImpeller:PES 30%GFInstallation:Range of ambient temperature:0 .. 40 °CMaximum operating pressure:10 barPipe connection:G 1 1/2″Pressure rating:PN10(@):180 mmElectrical data:Power input – P1:9 .. 92 WMains frequency:50 HzRated voltage:1 x 230 VMaximum current consumption:0.09 .. 0.74 AEnclosure class (IEC 34-5):X4DInsulation class (IEC 85):FOthers:Energy (EEI):0.22Net weight:4.38 kgGross weight:4.78 kgShipping volume:0.012 m³Danish VVS No.:380760060Finnish:LVI NO 4615256Country of origin:DECustom tariff no.:84137030
