Right Side Rising Tilting Swing Gate Hinge System (Gloss Black) Low Rise Version

Rising Gate Hinge System-Low Rise Version The rising hinge system allows for a tilted opening angle beginning from when the gate begins its opening till it reaches the full open position, this allows the special hinge system to open when a driveway has a grade uphill. Typically the hinge separation will determine the final rise amount, the close the top and bottom hinges are to one another the greater the rise, the further away from one another the less the rise amount. Please see the chart below on some typical examples. ✓ Steel Hinges ✓ Ball Joint in Each Hinge ✓ Gloss Black Colour ✓ Bottom support plate included for weightier gates ✓ Maximum 150KG capacity Rising Gate Guideline (LOW RISE VERSION) Gate Width (mm) Approximate.Gate Rise (mm) Hinge Separation (mm) 900 180 750 900 155 900 900 105 1360 900 90 1650 900 130 1060 900 120 1200 900 90 1400 900 100 1460 900 85 1760 900 80 1900 1200 160 1060 1200 145 1200 1200 130 1360 1200 110 1400 1200 120 1460 1200 110 1650 1200 100 1760 1200 95 1900 1500 190 1060 1500 168 1200 1500 150 1360 1500 130 1400 1500 140 1460 1500 125 1650 1500 120 1760 1500 115 1900 1800 300 750 1800 255 900 1800 215 1060 1800 190 1200 1800 170 1360 1800 155 1400 1800 160 1460 1800 145 1650 1800 140 1760 1800 130 1900 2100 250 1060 2100 255 1200 2100 200 1360 2100 180 1400 2100 180 1460 2100 165 1650 2100 155 1760 2100 150 1900
