Left Side Rising Tilting Swing Gate Hinge System (Gloss Black) High Rise Version

Rising Gate Hinge System-High Rise Version The rising hinge system allows for a tilted opening angle beginning from when the gate begins its opening till it reaches the full open position, this allows the special hinge system to open when a driveway has a grade uphill. Typically the hinge separation will determine the final rise amount, the close the top and bottom hinges are to one another the greater the rise, the further away from one another the less the rise amount. Please see the chart below on some typical examples. ✓ Steel Hinges ✓ Ball Joint in Each Hinge ✓ Gloss Black Colour ✓ Bottom support plate included for weightier gates ✓ Maximum 150KG capacity Rising Gate Guideline (HIGH RISE VERSION) Gate Width (mm) Gate Rise (mm) Hinge Separation (mm) 900 275 750 900 235 900 900 160 1360 900 140 1650 900 200 1060 900 180 1200 900 140 1400 900 150 1460 900 130 1760 900 125 1900 1200 240 1060 1200 220 1200 1200 195 1360 1200 170 1400 1200 180 1460 1200 165 1650 1200 150 1760 1200 145 1900 1500 290 1060 1500 255 1200 1500 230 1360 1500 200 1400 1500 210 1460 1500 190 1650 1500 180 1760 1500 175 1900 1800 460 750 1800 390 900 1800 330 1060 1800 290 1200 1800 260 1360 1800 235 1400 1800 240 1460 1800 220 1650 1800 210 1760 1800 200 1900 2100 380 1060 2100 385 1200 2100 300 1360 2100 270 1400 2100 270 1460 2100 250 1650 2100 235 1760 2100 225 1900
